DL205 Analog I/O Manual, 7th Edition Rev. D
1-8
Chapter 1: Getting Started
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
Analog Output
Specification F2-02DA-1, (L) F2-02DA-2, (L)
Channels 2 2
Output Ranges 4–20 mA
0–5V, 0–10V,
-5–+5V,
-10–+10V
Resolution 12 bit (1 in 4096) 12 bit (1 in 4096)
Output Type Single ended Single ended
See Chapter... 8 9
Analog Output
Specification F2-08DA-1 F2-08DA-2
Channels 8 8
Output Ranges 4–20 mA 0–5V, 0–10V
Resolution 12 bit (1 in 4096) 16 bit (1 in 4096)
Output Type Single ended Single ended, 1 common
See Chapter... 10 11
Analog Output
Specification F2-02DAS-1 F2-02DAS-2
Channels 2 8
Output Ranges 4–20 mA 0–5V, 0–10V
Resolution 16 bit (1 in 65536) 16 bit (1 in 65536)
Output Type Current sourcing Isolated
See Chapter... 12 13
Combination Analog
Specification F2-4AD2DA
Input Channels 4
Output Channels 2
Input Ranges 4–20 mA
Output Ranges 4–20 mA
Resolution 12 bit (1 in 4096)
Channel Isolation Non-isolated (one common)
Input and Output Types Single ended
Maximum Input Inaccuracy
w 0.3% at 25-C (77-F),
w 0.45% at 0- - 60-C (32- - 140-F)
Maximum Output Inaccuracy
w 0.1% at 25-C (77-F),
w 0.3% at 0- - 60-C (32- - 140-F)
See Chapter 14
