AutomationDirect DL205 Manual

DL205 Analog Manual, 7th Edition Rev. D
3-3
Chapter 3: F2-04AD-2, F2-04AD-2L, 4-Channel Analog Voltage Input
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
All specifications are the same for both modules except for the input voltage requirements.
Review these specifications to make sure the module meets your application requirements.
* NOTE: Values in parenthesis with an asterisk are for older modules with two circuit board design and date codes 0609F4
and previous. Values not in parenthesis are for single circuit board models with date code 0709G and above.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
Input Specifications
Number of Channels
4, single ended (one common)
Input Range
0–5 VDC, 0–10 VDC, W5V, w10V
Resolution
12 bit (1 in 4096) unipolar (0–4096)
13 bit (1 in 8192) bipolar (-4095 – +4095)
Common Mode Rejection
- 50 db at 800Hz
Step Response
8.2ms (*10ms) to 95% of full step change
Crosstalk
-70 db, 1 count maximum
Active Low-pass Filtering
-3 db at 80Hz, 2 poles (-12 db per octave)
Input Impedance
Greater than 20Mq
Absolute Maximum Ratings
-75 – +75 VDC
Converter Type
Successive appropximation
Linearity Error (End to End)
± 1 count (0.025% of span) maximum unipolar
± 2 counts maximum bipolar
Input Stability
± 1 count
Full Scale Calibration Error
(Offset error included)
± 3 counts maximum
Offset Calibration Error
± 1 count maximum (0V input)
Maximum Inaccuracy
± 0.1% @ 25°C (77°F)
± 0.3% 0–60°C (32–140°F)
Accuracy vs. Temperature
± 50ppm / °C full scale calibration change (including maximum
offset change of 2 counts)
General Specifications
PLC Update Rate
1 channel per scan maximum (DL230 CPU)
4 channels per scan maximum (DL240/250 - 1/260 CPU)
Digital Inputs
Input points required
12 binary data bits, 2 channel ID bits, 1 sign/diagnostic bit,
1 diagnostic bit
16 point (X) input module
Power Budget Requirement
110mA (*60mA maximum, 5VDC (supplied by base)
External Power Supply
5mA (*90mA max., 10–30 VDC (*18–26.4 VDC/F2-04AD-2)
90mA maximum, 10–15 VDC (F2-04AD-2L)
Operating Temperature
0–60°C (32°–140°F)
Storage Temperature
-20–70°C (-4°–158°F)
Relative Humidity
5–95% (non-condensing)
Environmental Air
No corrosive gases permitted
Vibration
MIL STD 810C 514.2
Shock
MIL STD 810C 516.2
Noise Immunity
NEMA ICS3-304
One count in the specification tables is equal to one least significant bit of the analog data value ( 1 in 4096).
