Chapter 5: F2-08AD-2, 8-Ch. Analog Voltage Input
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
The following tables provide the specifications for the F2–08AD–2 Analog Input Module.
Review these specifications to make sure the module meets your application requirements.
* NOTE: Values in parenthesis with an asterisk are for older modules with two circuit board design and date codes 0609D4
and previous. Values not in parenthesis are for single circuit board models with date code 0709E1 and above.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
Input Specifications
Number of Channels
8, single ended (one common)
Input Ranges
0–5V, 0–10V, ±5V, ±10V
Resolution
12 bit (1 in 4096) unipolar (0 – 4095)
13 bit (1 in 8192) bipolar (– 4095 – +4095)
Step Response
1.0 ms (* 4 ms) – 95% of full step change
Crosstalk
–70 dB, 1 count maximum
Active Low-pass Filtering
–3 dB @ 200Hz (– 6 dB per octave)
Input Impedance
Greater than 20Mq
Maximum Continuous Overload
-75 – +75VDC
Linearity Error (End to End)
±0.025% of span (±1 count maximum unipolar)
(±2 count maximum bipolar)
Input Stability
±1 count
Full Scale Calibration Error
(Offset error not included)
±3 counts maximum
Offset Calibration Error
±1 count maximum, @ 0VDC
Maximum Inaccuracy
±0.1% @ 25°C
±0.3% 0–60°C (32–140°F)
Accuracy vs. Temperature
±50 ppm/°C maximum full scale calibration
(including maximum offset change of 2 counts)
General Specifications
PLC Update Rate
1 channel per scan maximum (DL230 CPU)
8 channels per scan maximum (DL240/250 – 1/260 CPU)
Data Acquisition Time
3 ms/channel (asynchronous)
Digital Inputs
Input points required
12 binary data bits, 1 sign bit 3 channel ID bits,
1 diagnostic bit
16 point (X) input module
Power Budget Requirement
100mA (* 60mA) maximum, 5VDC (supplied by base)
External Power Supply
5mA (* 80mA) maximum, 10–30 (* 18–26.4) VDC
Operating Temperature
0 –60°C (32–140°F)
Storage Temperature
-20–70°C (-4–158°F)
Relative Humidity
5–95% (non-condensing)
Environmental air
No corrosive gases permitted
Vibration
MIL STD 810C 514.2
Shock
MIL STD 810C 516.2
Noise Immunity
NEMA ICS3-304
* One count in the specification tables is equal to one least significant bit of the analog data value ( 1 in 4096).
