DL205 Analog Manual, 7th Edition Rev. D
16-7
Chapter 16: F2-8AD4DA-2, 8-Ch. In / 4-Ch. Out Analog Voltage Combination
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
C
D
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
C
D
Wiring Diagram
The F2-8AD4DA-2 module has a removable connector to simplify wiring. Simply squeeze
the top and bottom retaining clips and gently pull the connector from the module. Use the
following diagram to connect the field wiring.
The diagram shows one power supply for both the module and the I/O signal loops. If
a separate module and transmitter supplies are to be used, connect the power supply 0V
commons together.
NOTE 1: Connect shields to the 0V of the module; do not connect both ends of the shield.
shield, Channel 3
CH1 ADC
CH2 ADC
CH4 ADC
CH3 ADC
CH6 ADC
AC or DC
Voltage transmitter
shield, Channel 8
transmitter
4--wire voltage
See Note 1
CH8 ADC
V8+
CH7 ADC
COM
Voltage transmitter
shield, Channel 5
transmitter
2--wire voltage
V5+
Isolated analog
circuit co mmon
Voltage transmitter
transmitter
3--wire voltage
COM
+
V3+
CH5 ADC
COM
CH1 DAC
CH2 DAC
COM
CH4 DAC
CH3 DAC
Isolated analog
circ uit power
User 24VDC
supply
COM
24VDC+
0VDC--
V1+
V2+
V3+
V4+
Voltage output
Channel 2
--
Voltage output
Channel 3
--
Voltage output
Channel 4
--
Voltage output
Channel 1
--
See Note 1
Internal module wiring
Transmitter power
+
+
+
+
See Note 1
See Note 1
IN/
OUT
F2-8AD4DA-2
ANALOG
0V
OUT2
OUT3
0V
IN2
IN3
0V
IN6
IN7
24V
OUT1
0V
OUT4
IN1
0V
IN4
IN5
0V
IN8
18-26.4VDC 80mA
8 INPUTS
0-5/0-10VDC
4 OUTPUTS
0-5/0-10VDC
