DL205 Analog Manual, 7th Edition Rev. D
16-13
Chapter 16: F2-8AD4DA-2, 8-Ch. In / 4-Ch. Out Analog Voltage Combination
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
C
D
Number of I/O Channels Enabled & Data Format
Load this V-memory location with a constant that specifies the number of enabled I/O
channels and their data formats. The upper byte applies to the inputs, and the lower byte
applies to the outputs. The most significant nibbles specify the data formats, and the least
significant nibbles specify the number of channels enabled.
Input Selection Resolution Bits
Each of the eight input channels can be individually disabled or configured for 12, 14, or 16
bit resolution.
V36403: (specific memory location will vary depending upon the base and slot location).
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
C
D
Expansion Base D2-CM #3: Analog In/Out Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of I/O Channels
Enabled & Format
V36200 V36201 V36202 V36203 V36204 V36205 V36206 V36207
Input Pointer
V36210 V36211 V36212 V36213 V36214 V36215 V36216 V36217
Output Pointer
V36220 V36221 V36222 V36223 V36224 V36225 V36226 V36227
Input Resolutions
V36230 V36231 V36232 V36233 V36234 V36235 V36236 V36237
(Reserved)
V36240 V36241 V36242 V36243 V36244 V36245 V36246 V36247
Input Track & Hold
V36250 V36251 V36252 V36253 V36254 V36255 V36256 V36257
Expansion Base D2-CM #4: Analog In/Out Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of I/O Channels
Enabled & Format
V36300 V36301 V36302 V36303 V36304 V36305 V36306 V36307
Input Pointer
V36310 V36311 V36312 V36313 V36314 V36315 V36316 V36317
Output Pointer
V36320 V36321 V36322 V36323 V36324 V36325 V36326 V36327
Input Resolutions
V36330 V36331 V36332 V36333 V36334 V36335 V36336 V36337
(Reserved)
V36340 V36341 V36342 V36343 V36344 V36345 V36346 V36347
Input Track & Hold
V36350 V36351 V36352 V36353 V36354 V36355 V36356 V36357
V-memory Locations for No. of I/O Channels Enabled & Format
No. of Channels Enabled
1 2 3 4 5 6 7 8
BCD Input
K01xx K02xx K03xx K04xx K05xx K06xx K07xx K08xx
Binary Input
K81xx K82xx K83xx K84xx K85xx K86xx K87xx K88xx
BCD Output
Kxx01 Kxx02 Kxx03 Kxx04 n/a n/a n/a n/a
Binary Output
Kxx81 Kxx82 Kxx83 Kxx84 n/a n/a n/a n/a
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R-
8H
R-
8L
R-
7H
R-
7L
R-
6H
R-
6L
R-
5H
R-
5L
R-
4H
R-
4L
R-
3H
R-
3L
R-
2H
R-
2L
R-
1H
R-
1L
To Next Page
