DL205 Analog Manual, 7th Edition Rev. D
15-5
Chapter 15: F2-8AD4DA-1 8-Ch. In / 4-Ch. Out Analog Current Combination
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
B
C
D
Module Placement and Configuration Requirements
The F2-8AD4DA-1 analog current input/output module requires 32 discrete input and 32
discrete output points.
The module can be installed in any non-CPU slot of D2-250-1 or D2-260 local bases,
D2-CM expansion bases, H2-EBC(100)(-F) Ethernet remote bases, H2-PBC Profibus slave
bases, or H2-WPLCx-xx WinPLC bases.
NOTE: The module is NOT supported by D2-230, D2-240, or D2-250 CPUs. It is also not supported by
D2-RMSM and D2-RSSS remote I/O master/slave modules.
The available power budget may also be a limiting factor. Check the user manual for the
particular module of CPU and I/O base for more information regarding power budget and
number of local, local expansion, or Ethernet remote I/O points.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
b
C
D
General Module Specifications
Digital Input and Output Points Required
32 point (X) Inputs
32 point (Y) Outputs
Power Budget Requirement
35mA @ 5VDC (supplied by the base)
External Power Supply Requirement
18–26.4 VDC, 100mA maximum plus 20mA per loop output
Field Side to Logic Side Isolation
1800VAC applied for 1 second (100% tested)
Insulation Resistance
>10Mq @ 500VDC
Operating Temperature
0 – 60°C (32–140°F); IEC60068-2-14
Storage Temperature
–20 – 70°C (- 4 – 158°F); IEC60068-2-1, -2-2, -2-14
Relative Humidity
5 – 95% (non-condensing); IEC60068-2-30
Environmental Air
No corrosive gases permitted; EN61131-2 pollution degree 1
Vibration
MIL STD 810C 514.2; IEC60068-2-6
Shock
MIL STD 810C 516.2; IEC60068-2-27
Noise Immunity
NEMA ICS3-304; IEC61000-4-2, -4-3, -4-4
Emissions
EN61000-6-4 (conducted and radiated RF emissions)
Module Location
Any non-CPU slot in local, expansion, or Ethernet remote base
of DL205 system with DL250-1 or DL260 CPU
Field Wiring
19 point removable terminal block included.
Optional remote wiring using ZL-CM20 remote feed-through
terminal block module and ZL-2CBL2# cable.
Agency Approvals
UL508; UL6079-15 Zone 2; CE (EN61131-1)
