Chapter 11: F2-08DA-2, 8-Channel Analog Voltage Output
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
The following tables provide the specifications for the F2–08DA –2 Analog Output Module.
NOTE: One count in the specifications table is equal to one least significant bit of the analog data value (1 in 4096)
Analog Output Configuration Requirements
The F2-08DA-2 Analog output appears as a 16-point discrete output module. The module
can be installed in any slot of a DL205 PLC, but the available power budget and discrete
I/O points are the limiting factors. Check the DL205 PLC User Manual for the partic-
ular model of CPU and I/O base being used for information regarding power budget and
number of local, local expansion or remote I/O points.
Output Specifications
Number of Channels
8, single-ended
Output Range
0–5V, 0–10V
Resolution
12 bit (1 in 4096)
Output Type
Voltage sourcing
Peak Output Voltage
15VDC (clamped by transient voltage suppressor)
Load Impedance
1kq (0–5V range); 10kq (0–10V range)
Load Capacitance
0.01 µF maximum
Linearity Error (end to end)
± 1 count (± 0.025% of full scale) maximum
Conversion Settling Time
400µs maximum (full scale change)
4.5 – 9.0 ms for digital out to analog out
Full-scale Calibration Error
(offset error included)
± 12 counts maximum, @ 25°C (77°F)
Offset Calibration Error
± 3 counts maximum, @ 25°C (77°F)
Maximum Inaccuracy
± 0.3% @ 25°C (77°F)
± 0.45% 0–60°C (32–140°F)
Accuracy vs. Temperature
± 57ppm/°C full scale calibration change
(including maximum offset change of 2 counts)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
General Specifications
PLC Update Rate
1 channel per scan maximum (multiplexing)
8 channels per scan maximum (pointer –
DL240/DL250-1/DL260 only)
Digital Outputs /
Output Points Required
12 binary data bits, 3 channel ID bits, 1 output enable bit /
16 (Y) output points required
Power Budget Requirement
60mA @ 5VDC (supplied by the base)
External Power Supply
24VDC(± 10%), 140mA (outputs fully loaded)
Operating Temperature
0–60°C (32–140°F)
Storage Temperature
-20–70°C (-4–158°F)
Relative Humidity
5–95% (non-condensing)
Environmental Air
No corrosive gases permitted
Vibration
MIL STD 810C 514.2
Shock
MIL STD 810C 516.2
Noise Immunity
NEMA ICS3-304
