The following tables show the special V-memory locations used by the DL240, DL250-1 and
DL260 for the CPU base and local expansion base I/O slots. Slot 0 (zero) is the module next to
the CPU or D2-CM module. Slot 1 is the module two places from the CPU or D2-CM, and
so on. Remember, the CPU only examines the pointer values at these locations after a mode
transition. Also, if the DL230 (multiplexing) method is used, verify that these addresses in the
CPU are 0 (zero).
The table below applies to the DL240, DL250-1 and DL260 CPU base.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
CPU Base: Analog Output Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V7660 V7661 V7662 V7663 V7664 V7665 V7666 V7667
Storage Pointer
V7700 V7701 V7702 V7703 V7704 V7705 V7706 V7707
Expansion Base D2-CM #1: Analog Output Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36000 V36001 V36002 V36003 V36004 V36005 V36006 V36007
Storage Pointer
V36020 V36021 V36022 V36023 V36024 V36025 V36026 V36027
Expansion Base D2-CM #2: Analog Output Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36100 V36101 V36102 V36103 V36104 V36105 V36106 V36107
Storage Pointer
V36120 V36121 V36122 V36123 V36124 V36125 V36126 V36127
Expansion Base D2-CM #3: Analog Output Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36200 V36201 V36202 V36203 V36204 V36205 V36206 V36207
Storage Pointer
V36220 V36221 V36222 V36223 V36224 V36225 V36226 V36227
Expansion Base D2-CM #4: Analog Output Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36300 V36301 V36302 V36303 V36304 V36305 V36306 V36307
Storage Pointer
V36320 V36321 V36322 V36323 V36324 V36325 V36326 V36327
The table below applies to the DL250-1 or the DL260 CPU base 1.
The table below applies to the DL250-1 or the DL260 CPU base 2.
The table below applies to the DL260 CPU base 3.
The table below applies to the DL260 CPU base 4.
