DL205 Analog Manual, 7th Edition Rev. D
14-17
Chapter 14: F2-4AD2DA 4-Ch. In / 2-Ch. Out Analog Combination
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
The following tables show the special V-memory locations used by the DL240, DL250-1 and
DL260 for the CPU base and local expansion base I/O slots. Slot 0 (zero) is the module next to
the CPU or D2-CM module. Slot 1 is the module two places from the CPU or D2-CM, and
so on. Remember, the CPU only examines the pointer values at these locations after a mode
transition. Also, if the DL230 (multiplexing) method is used, verify that these addresses in the
CPU are 0 (zero).
The table below applies to the DL240, DL250-1 and DL260 CPU base.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
CPU Base: Analog In/Out Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V7660 V7661 V7662 V7663 V7664 V7665 V7666 V7667
Input Pointer
V7670 V7671 V7672 V7673 V7674 V7675 V7676 V7677
Output Pointer
V7700 V7701 V7702 V7703 V7704 V7705 V7706 V7707
Expansion Base D2-CM #1: Analog In/Out Module Slot-Dependent V-memory Locations
Slot.
0 1 2 3 4 5 6 7
No. of Channels
V36000 V36001 V36002 V36003 V36004 V36005 V36006 V36007
Input Pointer
V36010 V36011 V36012 V36013 V36014 V36015 V36016 V36017
Output Pointer
V36020 V36021 V36022 V36023 V36024 V36025 V36026 V36027
Expansion Base D2-CM #2: Analog In/Out Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36100 V36101 V36102 V36103 V36104 V36105 V36106 V36107
Input Pointer
V36110 V36111 V36112 V36113 V36114 V36115 V36116
V36117
Output Pointer
V36120 V36121 V36122 V36123 V36124 V36125 V36126 V36127
Expansion Base D2-CM #3: Analog In/Out Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36200 V36201 V36202 V36203 V36204 V36205 V36206 V36207
Input Pointer
V36210 V36211 V36212 V36213 V36214 V36215 V36216
V36217
Output Pointer
V36220 V36221 V36222 V36223 V36224 V36225 V36226 V36227
Expansion Base D2-CM #4: Analog In/Out Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36300 V36301 V36302 V36303 V36304 V36305 V36306 V36307
Input Pointer
V36310 V36311 V36312 V36313 V36314 V36315 V36316
V36317
Output Pointer
V36320 V36321 V36322 V36323 V36324 V36325 V36326 V36327
The table below applies to the DL250-1 or the DL260 CPU base 1.
The table below applies to the DL250-1 or the DL260 CPU base 2.
The table below applies to the DL260 CPU base 3.
The table below applies to the DL260 CPU base 4.
