DL205 Analog Manual, 7th Edition Rev. D
4-14
Chapter 4: F2-08AD-1, 8-Channel Analog Current Input
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
b
C
D
The tables below show the special V-memory locations used by the DL240, DL250-1 and
DL260 for the CPU base and local expansion base I/O slots. Slot 0 (zero) is the module next
to the CPU or the D2-CM module. Slot 1 is the module two places from the CPU or the
D2-CM, and so on. Remember, the CPU only examines the pointer values at these locations
after a mode transition. Also, if the DL230 (multiplexing) method is used, verify that these
addresses in the CPU are zero.
The table below applies to the DL240, DL250-1 and DL260 CPU base.
The table below applies to the DL250-1 or the DL260 expansion base 1.
The table below applies to the DL250-1 or the DL260 expansion base 2.
The table below applies to the DL260 CPU expansion base 3.
The table below applies to the DL260 CPU expansion base 4.
CPU Base: Analog Input Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V7660 V7661 V7662 V7663 V7664 V7665 V7666 V7667
Storage Pointer
V7670 V7671 V7672 V7673 V7674 V7675 V7676 V7677
Expansion Base D2-CM #1: Analog Input Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36000 V36001 V36002 V36003 V36004 V36005 V36006 V36007
Storage Pointer
V36010 V36011 V36012 V36013 V36014 V36015 V36016 V36017
Expansion Base D2-CM #2: Analog Input Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36100 V36101 V36102 V36103 V36104 V36105 V36106 V36107
Storage Pointer
V36110 V36111 V36112 V36113 V36114 V36115 V36116 V36117
Expansion Base D2-CM #3: Analog Input Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36200 V36201 V36202 V36203 V36204 V36205 V36206 V36207
Storage Pointer
V36210 V36211 V36212 V36213 V36214 V36215 V36216 V36217
Expansion Base D2-CM #4: Analog Input Module Slot-Dependent V-memory Locations
Slot
0 1 2 3 4 5 6 7
No. of Channels
V36300 V36301 V36302 V36303 V36304 V36305 V36306 V36307
Storage Pointer
V36310 V36311 V36312 V36313 V36314 V36315 V36316 V36317
