4. Controlling dimmers and fixtures - Page 91
TitanUniversal_Man_v10_QU.doc 15 March 2016
If intensity levels are controlled by an effect they are shown in yellow
with a tilde symbol (~).
If the intensity is controlled from a cue or cue list the name of the cue
will be shown.
The IPCGBESFX states of the fixture are also highlighted if any
attributes have been set in the programmer.
If colour halos are set for the fixture buttons, the halo is also
displayed around the fixture intensity. This option can be changed to
show the automatic fixture colours, see below.
• Filter the view to show only a certain type of fixture using the
buttons on the left
• Change the display order of the fixtures using the [Sort]
context menu buttons – User Number, Last Selected or DMX
Address.
• Click on a fixture to select it, you can then edit the intensity
directly.
• Press Window Open followed by a fixture button to show more
det
ailed information about the fixture.
The context menu options give you settings to change how the
window is displayed.
The first option lets you only show fixtures in a particular state:
All – all fixtures (default)
Stage – fixtures with intensity above zero
Programmer – fixtures in the programmer
Selected – fixtures which are selected
Live cues – only intensities coming from active cues
Connected cue – only fixtures in the currently connected cue (for cue
lists or chases)
Frozen – fixtures with frozen intensity
The second option changes sort order as described above
[Search] allows you to enter characters to search for in the legend or
user number, matching fixtures will be shown as you type. When
Search is active a search bar is shown at the top of the window, click
the X to remove the search filter or click on the text to modify the
search string.
[View If] lets you click on a group and/or playback to show only the
fixtures in that group or playback. For a chase or cue list, this will
include all fixtures in all the cues of the chase/list. The filter settings
are shown in a bar at the top of the window, click the X to remove
the filter or click on the bar to change the group/playback.
[Open Channel Grid] opens the Channel Grid window described in the
previous section.
In the Window Appearance Settings (cog button) there are further
display options. Turning off some of the options will reduce the size of
each fixture button which may be useful if you want to get more
fixtures on the screen.
• Filter Fixtures Shown/Hidden: Shows or hides the fixture
selection buttons on the left
