4. Controlling dimmers and fixtures - Page 75
TitanUniversal_Man_v10_QU.doc 15 March 2016
To go back to normal, press Unfold then [Exit Unfold].
You can also use the numeric keypad to quickly select cells. The
syntax is as follows:
.
all sub fixtures of
selection
n.
all sub fixtures of
fixture n
. THRO .j
sub fixtures 1Æj of
all selected
fixtures
n. THRO
all sub fixtures of
fixture nÆlast
consecutive of
type n
THRO .j
shorthand for
above
n. THRO i
sub fixtures 1Æi
of fixture n
.m
sub fixture m of all
selected fixtures
n. THRO i.j
sub fixtures 1Æj
of fixtures nÆi
.m THRO
sub fixtures
mÆlast of all
selected fixtures
n.m
sub fixture m of
fixture n
.m THRO .j
sub fixtures mÆj
of all selected
fixtures
n.m THRO
sub fixtures
mÆlast of fixture
n
.m THRO j
shorthand for
above
n.m THRO i
sub fixtures mÆi
of fixture n
n THRO i.
all sub fixtures of
fixtures nÆi
n.m THRO i.
sub fixture
mÆlast of fixtures
nÆi
n THRO i.j
sub fixture j of
fixtures nÆi
n.m THRO i.j sub fixtures mÆj
of fixtures nÆi
n THRO .j
sub fixture 1Æj of
fixture n
n.m THRO .j sub fixtures mÆj
of fixture n
4.1.5 Changing attributes using the wheels
“Attributes” are the functions of the fixture, like pan, tilt, colour,
dimmer, etc. You select which attributes you want to modify using
the Attribute Bank buttons and set values using the wheels. The
attributes available depend on the fixture type. Dimmer channels only
have a dimmer attribute.
You can also select attributes by touching the IPCGBES buttons on
the touch screen, and modify them using the Attributes workspace
window; this is described in the next section.
Each attribute button controls several attributes, one on each wheel.
1> With some fixtures selected, press the button for the attribute
to be changed
2> Turn the wheels to set the attribute. The display above the
wheels shows which attributes are being controlled, and the
settings which are available scroll up and down as you turn the
wheels.
