Baumuller b maXX BM5800 - Page 227

Description of the Software Modules and Parameters
Parameter manual b maXX BM5800
Document No.: 5.16029.03
227
of 814
3
21 Trigger frequency
0: one-time trigger
a new measure does not occur until measuring encoder has been reac-
tivated with P124.2
1: Continuous triggering 
Measurements always occur; however, within a sampling cycle of the
module (1
ms), only the first event will be triggered.
22…
28
Measurement "Encoder 2 with Trigger Zero Pulse"
22 Activation channel measurement positive edge
(Enc2TrZpPosValRev/Enc2TrZpPosValPhi)
0: switch off
1: switch on
23 Activation channel measurement negative edge
(Enc2TrZpNegValRev/Enc2TrZpNegValPhi)
0: switch off
1: switch on
24 Reserved
25 Activation Qualification with digital input
0: Qualification off
1: Qualification on
26 Selection digital input for qualification
0: Qualification zero pulse with digital input TP1
1: Qualification zero pulse with digital input TP2
27 Selection Signal Level for qualification
0: Zero pulse trigger active when digital input = low
1: Zero pulse trigger active when digital input = high
28 Trigger frequency
0: one-time trigger
a new measure does not occur until measuring encoder has been reac-
tivated with P124.2
1: Continuous triggering 
Measurements always occur; however, within a sampling cycle of the
module (1
ms), only the first event will be triggered.
29 Reserved
30 For all channels:
0: Delete measuring values, if channel is switched on
1: Delete measuring values, if channel is switched off
31 Activation filter 500 µs for measuring encoder digital input TP2 (effects only for
measuring encoder, to all encoder)
1: Filtering with 500 µs
0:No filtering (-> 4 µs)
Bit Meaning
