Configuration
Parameter manual b maXX BM5800
Document No.: 5.16029.03 Baumüller Nürnberg GmbH
228
of 814
3.4
124.2 Activation Command
Command to delete one or more measurements. The following actions will be performed
for the corresponding channel:
m Deleting the associated status bit (measurement occurred / not occurred) in status
m Setting measured values of individual channels to zero
m Reactivation of an already (through Parameter 124.1) activated channel
Toggling the corresponding bit will trigger the command.
The parameter can be used to delete the indexes / latched values of the measuring en-
coder during active operation, but the application is not necessary.
Bit Meaning
Encoder 1
0 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger digital
input TP1 positive edge
1 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger digital
input TP1 negative edge
2 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger digital
input TP2 positive edge
3 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger digital
input TP2 negative edge
4 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger Zero
Pulse positive edge
5 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 1 with Trigger Zero
Pulse negative edge
6 ... 7 Reserved
Encoder 2
8 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 2 with Trigger digital
input TP1 positive edge
9 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 2 with Trigger digital
input TP1 negative edge
10 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 2 with Trigger digital
input TP2 positive edge
