124.3 Status
Status of the measuring encoder.
11 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 2 with Trigger digital
input TP2 negative edge
12 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 2 with Trigger Zero
Pulse positive edge
13 0->1, 1->0:
Measurement Channel "Delete / reactivate Encoder 2 with Trigger Zero
Pulse negative edge
14 ... 15 Reserved
Bit Meaning
Bit Meaning
0 Measured value storage Measurement Channel "Encoder 1 with Trigger dig-
ital input TP1 positive edge":
0: Switched off
1: Switched on
1 Measured value storage Measurement Channel "Encoder 1 with Trigger dig-
ital input TP1 negative edge":
0: Switched off
1: Switched on
2 Measured value storage Measurement Channel "Encoder 1 with Trigger dig-
ital input TP2 positive edge":
0: Switched off
1: Switched on
3 Measured value storage Measurement Channel "Encoder 1 with Trigger dig-
ital input TP2 negative edge":
0: Switched off
1: Switched on
4 Measured value storage Measurement Channel "Encoder 1 with Trigger
Zero Pulse positive edge":
0: Switched off
1: Switched on
5 Measured value storage Measurement Channel "Encoder 1 with Trigger
Zero Pulse negative edge":
0: Switched off
1: Switched on
6 Measured value storage Measurement Channel "Encoder 2 with Trigger dig-
ital input TP1 positive edge":
0: Switched off
1: Switched on
