Configuration
Parameter manual b maXX BM5800
Document No.: 5.16029.03 Baumüller Nürnberg GmbH
230
of 814
3.4
7 Measured value storage Measurement Channel "Encoder 2 with Trigger dig-
ital input TP1 negative edge":
0: Switched off
1: Switched on
8 Measured value storage Measurement Channel "Encoder 2 with Trigger dig-
ital input TP2 positive edge":
0: Switched off
1: Switched on
9 Measured value storage Measurement Channel "Encoder 2 with Trigger dig-
ital input TP2 negative edge":
0: Switched off
1: Switched on
10 Measured value storage Measurement Channel "Encoder 2 with Trigger
Zero Pulse positive edge":
0: Switched off
1: Switched on
11 Measured value storage Measurement Channel "Encoder 2 with Trigger
Zero Pulse negative edge":
0: Switched off
1: Switched on
12 Status of the measured value storage Channel "Encoder 1 with Trigger digi-
tal input TP1" ("or" linked Bits 20,21):
0: No measured value stored yet
1: Measured value stored
13 Status of the measured value storage Channel "Encoder 1 with Trigger digi-
tal input TP2" ("or" linked Bits 22,23):
0: No measured value stored yet
1: Measured value stored
14 Status of the measured value storage Channel "Encoder 1 with Trigger Zero
Pulse " ("or" linked Bits 24,25):
0: No measured value stored yet
1: Measured value stored
15 Status of the measured value storage Channel "Encoder 2 with Trigger digi-
tal input TP1" ("or" linked Bits 26,27):
0: No measured value stored yet
1: Measured value stored
16 Status of the measured value storage Channel "Encoder 2 with Trigger digi-
tal input TP2" ("or" linked Bits 28,29):
0: No measured value stored yet
1: Measured value stored
17 Status of the measured value storage Channel "Encoder 2 with Trigger Zero
Pulse " ("or" linked Bits 30,31):
0: No measured value stored yet
1: Measured value stored
19 … 18 Reserved
Bit Meaning
