Description of the Software Modules and Parameters
Parameter manual b maXX BM5800
Document No.: 5.16029.03
231
of 814
3
Attention:
The status bits 12…17 and 20…21 remain set with continuous triggering of the corre-
sponding channel (P124.1) after the first measurement. For signaling, the additional use
of P124.4 is recommended where new measured values of the channels are signaled
through toggle bits.
124.4 Status 2
Extended status of the measuring encoder.
Toggle bits to signal new measurements with continuous triggering (refer to Z124.1–).
21…20 Status of measured value storage Measurement Channel "Encoder 1 with
Trigger digital input TP1":
00: No measured value stored yet
01: Measured value positive edge stored
10: Measured value negative edge stored
11: Measured value positive + negative edge stored
23…22 Status of measured value storage Measurement Channel "Encoder 1 with
Trigger digital input TP2":
00: No measured value stored yet
01: Measured value positive edge stored
10: Measured value negative edge stored
11: Measured value positive + negative edge stored
25…24 Status of measured value storage channel "Encoder 1 with Zero Pulse":
00: No measured value stored yet
01: Measured value positive edge stored
10: Measured value negative edge stored
11: Measured value positive + negative edge stored
27…26 Status of measured value storage Measurement Channel "Encoder 2 with
Trigger digital input TP1":
00: No measured value stored yet
01: Measured value positive edge stored
10: Measured value negative edge stored
11: Measured value positive + negative edge stored
29…28 Status of measured value storage Measurement Channel "Encoder 2 with
Trigger digital input TP2":
00: No measured value stored yet
01: Measured value positive edge stored
10: Measured value negative edge stored
11: Measured value positive + negative edge stored
31…30 Status of measured value storage channel "Encoder 2 with Zero Pulse":
00: No measured value stored yet
01: Measured value positive edge stored
10: Measured value negative edge stored
11: Measured value positive + negative edge stored
Bit Meaning
