Error messages and troubleshooting
Parameter manual b maXX BM5800
Document No.: 5.16029.03
753
of 814
4
1952 Data received for a complete telegram
is insufficient
Characters were received through a communication source; how-
ever, the telegram is incomplete and additional characters must be
received.
No response
2200 Error occurred in the FFT analyzer An error occurred in the function FFT Analysis. For an exact specifi-
cation, refer to Parameter 104.8 "FFT Info".
No response
2201 FFT result not ready for READING yet No response
2300 FPGA_RSP record is not available for
READING
No response
2598 Last reserved error number for platform
error
Platform errors are reserved error numbers that may have different
levels of importance on each platform. This range of numbers is
reserved so that platform specific error numbers (e.g. Windows error
numbers) do not have to be defined as generally valid in rc.h. These
error numbers can then be used as return codes within the platform
and may thereby not be transferred externally.
No response
2700 Fb Set value generator Set Value < Min
(target parameter)
One or more set values of the set value generator (FbSwg) are
smaller than the minimum value of the selected target parameter.
Testing is carried out to prevent overrun effects while writing to the
target parameter.
No response
2701 Fb Set value generator Set Value >
Max (target parameter)
One or more set values of the set value generator (FbSwg) are
greater than the maximum value of the selected target parameter.
Testing is carried out to prevent overrun effects while writing to the
target parameter.
No response
2702 Error in the configuration of the return
motion
General error in the configuration of the return motion detected by
the test function.
Cause:
m The motorized operation at mains failure is not permitted
(
Z130.10– Supply mode bit 1 = 0)
Pulse block
2703 Return motion target not reached The return motion positioning did not reach the target. This is
described in
Z148.2– Status bits 4, 8-11:
n Inhibit/interrupt by command in Z148.1– mode
n Interrupt due to hardware-ended pulse inhibit
n Interrupt due to higher-ordered error reaction
n Interrupt due to return-motion-own position error monitoring
2720 Cam generator - no input parameter
was selected
Selection of processing mode "parameter-controlled processing"
No input parameter was selected.
No response
2721 Cam generator - no reference parame-
ter was selected
Selection of relative mode, but no reference parameter was
selected.
No response
2722 Cam generator - no output parameter
was selected
No target parameter was selected. No response
2723 Cam generator - the output value was
limited
The output value of the cam is greater than the maximum value of
the target parameter or the output value is lower than the minimum
value of the target parameter.
Pulse block
2724 Cam generator - in the RAM no valid
cam was found
An attempt was made to start the cam generator, although there was
no applicable cam in the RAM
No response
2725 Cam generator - an error occurred
while loading the cam
An attempt to load a cam into the device failed.
m Possible causes:
n Cam has more than 1024 supporting points
n An attempt was made to load a cam, although another cam was
processing yet
n An attempt was made to load a wrong file. Only files with exten-
sion *.kbin can be loaded.
No response
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
