Error descriptions
Parameter manual b maXX BM5800
Document No.: 5.16029.03 Baumüller Nürnberg GmbH
754
of 814
4.5
2726 Cam generator - the active cam cannot
be used in this mode
In the "parameter-controlled processing" mode the cyclical process-
ing is selected. The count of supporting points must accord to power
2. This is not the case at the active cam (e.g. count of supporting
points is 256, 512 or 1024)
No response
2740 No polynomial curve data available It was tried to release the drive in the operation mode "Coupled
mode" but there is no polynomial curve data in the controller.
m Consequence:
The operation in the coupled mode isn't possible. Behavior accor-
dant to set error reaction.
Pulse block
2741 Invalid segment number detected At the polynomial curve generator an invalid segment number was
transferred for which there is no segment existent.
This error can occur at the transmission of the curve segments or at
a chain change.
m Consequence:
The transmitted curve segments are rejected.
Pulse block
2742 No valid start segment defined The start segment defined in the parameter Z122.7– isn't in the
polynomial curve.
m Consequence:
The polynomial curve generator cannot be activated.
Pulse block
2743 No cam data available in internal buffer The intermediate buffer doesn't include valid polynomial curve data.
Presumably the required data weren't able to be added in time. It is
recommended to reduce the speed of the master or to increase the
scope of the individual curve segments.
m Consequence:
The processing of the polynomial curves must be interrupted.
Pulse block
2744 Master axis in motion during synchroni-
zation
In the Z122.2– mode of the "Coupled mode" was set that the master
axis must stop during the synchronization phase. However a posi-
tion change was determined at the master axis position.
m Consequence:
Depending on the error reaction. If there is no reaction parameter-
ized, the drive processes the synchronization of the polynomial
curves anyway. However, the polynomial curve and the synchroni
-
zation movement overlap.
No response
2745 Invalid start position of the master axis A valid starting position of the master axis in the parameter Z122.8–
and Z122.9– was not defined.
m Cause
Based on the starting position the current master axis position
Z122.3– and Z122.4– are not within the linking of the active
curve.
Pulse block
2746 File handler busy Although the previous transmission was not completed yet a polyno-
mial curve was transmitted.
No response
2747 Transmitted file includes unknown
curve type
The transmitted curve contains an unknown curve type.
m Consequence:
The transmission is interrupted and the file is canceled.
No response
2748 An active curve could not be deleted It's not permitted to overwrite the polynomial curve completely
during processing. However, the reload by using a changed curve
segment would be possible.
m Consequence:
The previous curve is continued to be processed.
No response
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
