Summary of all Parameters
Parameter manual b maXX BM5800
Document No.: 5.16029.03
763
of 814
5
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write Axis-independent
29.1 Command UINT 0 0xffff 0 1:1 X
29.2 Status UINT 0 2 0 1:1 X
29.6 Input value FLOAT -5000000000 5000000000 0.0 1:1 X
29.7 Output Value FLOAT -5000000000 5000000000 0.0 1:1 X
29.8 Filter Order UINT 0 7 1 1:1 X
29.9 Coefficient a0 FLOAT -1000000 1000000 1.0 1:1 X
29.10 Coefficient a1 FLOAT -1000000 1000000 0.0 1:1 X
29.11 Coefficient a2 FLOAT -1000000 1000000 0.0 1:1 X
29.12 Coefficient a3 FLOAT -1000000 1000000 0.0 1:1 X
29.13 Coefficient a4 FLOAT -1000000 1000000 0.0 1:1 X
29.14 Coefficient a5 FLOAT -1000000 1000000 0.0 1:1 X
29.15 Coefficient a6 FLOAT -1000000 1000000 0.0 1:1 X
29.16 Coefficient a7 FLOAT -1000000 1000000 0.0 1:1 X
29.17 Coefficient b1 FLOAT -1000000 1000000 0.0 1:1 X
29.18 Coefficient b2 FLOAT -1000000 1000000 0.0 1:1 X
29.19 Coefficient b3 FLOAT -1000000 1000000 0.0 1:1 X
29.20 Coefficient b4 FLOAT -1000000 1000000 0.0 1:1 X
29.21 Coefficient b5 FLOAT -1000000 1000000 0.0 1:1 X
29.22 Coefficient b6 FLOAT -1000000 1000000 0.0 1:1 X
29.23 Coefficient b7 FLOAT -1000000 1000000 0.0 1:1 X
29.29 Filter cycle time FLOAT 62.5 1000 250 µs 1:1 X
29.30 Biquad filter 1 nominator
frequency
FLOAT 0 10000 0 Hz 1:1 X
29.31 Biquad filter 1 damping
nominator
FLOAT 0 10 0 1:1 X
29.32 Biquad filter 1 denomi-
nator frequency
FLOAT 0 10000 0 Hz 1:1 X
29.33 Biquad filter 1 damping
denominator
FLOAT 0 10 0 1:1 X
29.34 Biquad filter 2 nominator
frequency
FLOAT 0 10000 0 Hz 1:1 X
29.35 Biquad filter 2 damping
nominator
FLOAT 0 10 0 1:1 X
29.36 Biquad filter 2 denomi-
nator frequency
FLOAT 0 10000 0 Hz 1:1 X
29.37 Biquad filter 2 damping
denominator
FLOAT 0 10 0 1:1 X
29.38 Biquad filter 3 nominator
frequency
FLOAT 0 10000 0 Hz 1:1 X
29.39 Biquad filter 3 damping
nominator
FLOAT 0 10 0 1:1 X
29.40 Biquad filter 3 denomi-
nator frequency
FLOAT 0 10000 0 Hz 1:1 X
