Baumuller b maXX BM5800 - Page 770

Summary of all Parameters
Parameter manual b maXX BM5800
Document No.: 5.16029.03 Baumüller Nürnberg GmbH
770
of 814
5
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write Axis-independent
106.62 SSI bits angle UINT 0 31 12 1:1 X
106.63 SSI bits revolutions UINT 0 31 12 1:1 X
106.64 SSI angle UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
106.65 SSI revolutions UDINT 0 0xFFFFFFFF 0 1:1 X
106.70 Encoder excentricity
angular phase shift
UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
106.71 Encoder excentricity
angular amplitude
UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
106.72 State of encoder optimi-
zation
DINT 0 0xFF 0 1:1 X
106.75 Maximum harmonic UINT 0 3 0 1:1 X
106.76 Amplitudes of the har-
monics
UDINT 0 0xFFFFFFFF 0 Grad 1:1 X
106.77 Phases of the harmon-
ics
UDINT 0 0xFFFFFFFF 0 Grad 1:1 X
106.78 Correction angle DINT 0x80000000 0x7FFFFFFF 0 Grad 1:1
106.79 Speed for calculation of
excentricity
FLOAT 0 3000 600 Grad/s 1:1
106.81 DSL communication
error counter
UDINT 0 0xFFFFFFFF 0 1:1 X
106.90 Encoder angle fieldbus UDINT 0 0xFFFFFFFF 0 Grad 1:1 X X
106.91 Encoder speed fieldbus FLOAT -1000000 1000000 0 Grad/s 1:1 X X
106.92 Fieldbus deadtime FLOAT 0 5 2 ms 1:1 X
106.98 SSI bits extra data MSB UINT8 0 32 0 Bit 1:1 X
106.99 SSI bits extra data LSB UINT8 0 32 0 Bit 1:1 X
106.100 SSI extra data target
parameter MSB
UDINT 0 0xFFFFFFFF 0 1:1 X
106.101 SSI extra data target
parameter LSB
UDINT 0 0xFFFFFFFF 0 1:1 X
107.1 Version UINT 0 0xFFFF 0 1:1 X
107.2 Motor type STRING 1:1 X
107.3 Article number UDINT 0 0xFFFFFFFF 0 1:1 X
107.4 Serial number UDINT 0 0xFFFFFFFF 0 1:1 X
107.5 Nominal operation mode UINT 0 0xFFFF 0 1:1 X
107.6 Nominal power FLOAT 0 655.35 5 kW 1:1 X
107.7 Nominal speed UINT 1 65535 3000 U/min 1:1 X
107.8 Nominal voltage FLOAT 0 6553.5 0 V 1:1 X
107.9 Nominal current FLOAT 0 6553.5 3.5 A 1:1 X
107.10 Standstill current FLOAT 0 6553.5 0 A 1:1 X
107.11 Standstill torque FLOAT 0 42949672.95 0 Nm 1:1 X
107.12 Power factor FLOAT 0 1.000 0,9 1:1 X
107.13 Nominal frequency FLOAT 0 6553.5 0 Hz 1:1 X
107.14 Magnetic current FLOAT 0 6553.5 0.01 A 1:1 X
