2000X energy Power Supply Chapter 2: The 2000X energy Power Supply
Instruction Manual Features
011-003-991 EN 2-5
• Horn Scan: A scan to enhance selection of operating frequency and control parameters. This feature is
available in the DUPS only.
• Limits, Control: These are controls that are used in conjunction with the main weld mode. These user
programmed limits provide for additional control of the weld process.
• Limits, Reject: A class of user-definable process alarms that alert you if a part falls into a range that you
classified as reject parts.
• Limits, Suspect: A class of user-definable process alarms that alert you if a part falls into a range that
you have determined should be inspected.
• Memory: When Memory is turned on, weld parameters at the end of the cycle will be entered.
• Membrane Keyboard: For high reliability and immunity from factory dust and oils.
• Parallel Port: The parallel port supports printers.
• Parameter Entry through Keypad: A keypad is provided for direct entry. Plus (+) and Minus (–) keys
are provided for adjusting existing values.
• Parameter Range Checking: If you enter an invalid parameter the Power Supply shows you the valid
range.
• Password Protection: This feature allows you to secure your setup from unauthorized changes. You
can select your own password.
• Presets: The UPS is capable of storing up to 12 presets of power supply operating parameters depend-
ing on feature level and type of UPS.
• Pretrigger: This feature allows you to turn on the ultrasonics before contact with the part to increase
performance.
• Print, Background: This feature allows you to print the results of the previous cycle while performing a
new cycle.
• Print, Data: Prints one line of data depicting weld results.
• Print, Now: At any time you can request any printable items for the last cycle completed.
• Print, on Alarm: You can request any printable item whenever an alarm occurs. This gives you the infor-
mation you need to determine how your setup or limits can be changed.
• Print, on Sample: You can request any printable items based on a sampling rate. This facilitates auditing
your process and lot control.
• Printing, Weld History: At any time you can print all of the weld parameters from the last 50 cycles com-
pleted using your current setup.
• Rapid Traverse: Allows a high horn travel speed for a portion of the stroke. Once the set distance is
reached, travel speed is reduced to the downspeed setting.
• Ramp Starting: The starting of the Power Supply and horn is done at the optimum rate to reduce elec-
trical and mechanical stress on the system.
• Remote Terminal: With the optional remote terminal you can see full menus and weld results on a single
screen.
• Seek, Post Weld: This feature provides a Seek at the end of the cycle to automatically retune the Power
Supply.
• Seek: Ensures operation at resonance; minimizes tuning errors; and operates the stack at low amplitude
(approximately 5%), then provides a means of sensing and storing the resonant operating frequency
