2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual System Alarm Tables
011-003-991 EN 7-27
7.5.6 Setup Alarms and Messages
Table 7.8 Setup Alarms and Messages, with Probable Cause
and Corrective Action
Model
Display
Message
Alarm Condition/Cause Corrective Action
2000a
2000dt
Amp Step Conflict The distance you have set for the amplitude to step
is equal to or greater than the absolute distance
you have set.
Change the step distance for the
amplitude and/or the absolute distance
settings.
2000a
2000dt
Amp Step Conflict The energy level you have set for the amplitude to
step is in conflict with the energy level you have set
for the weld cycle.
Change the step energy for the amplitude
and/or the energy level for the weld cycle.
2000a
2000dt
Amp Step Conflict The time that you have set for the amplitude to
step is greater than the time that you have set for
the weld cycle.
Change the step time for the amplitude
and/or the time setting for the weld cycle.
2000a
2000dt
Amp Step Conflict The amplitude step value is equal to or greater
than the plus reject peak power limit value.
Change the amplitude step or +reject
peak power limit through the Alarm
Information screen or Setup menu.
2000a
2000dt
Amp Step Conflict The amplitude step value is equal to or greater
than the plus suspect peak power limit.
Change the amplitude step or +suspect
peak power limit through the Alarm
Information screen or Setup menu.
2000a
2000dt
Amp Step Conflict The amplitude step value is equal to or greater
than the plus reject energy limit.
Change the amplitude step or +reject
energy limit through the Alarm
Information screen or Setup menu.
2000a
2000dt
Amp Step Conflict The amplitude step value is equal to or greater
than the plus suspect energy limit.
Change the amplitude step or +suspect
energy limit through the Alarm
Information screen or Setup menu.
2000a
2000dt
Amp Step Conflict The amplitude step at power value is equal to or
greater than the peak power value. This alarm is
for peak power mode only.
Change the amplitude step or peak
power main parameter through the Alarm
Information screen or Setup menu.
2000a
2000dt
Amp Step Conflict The amplitude step at energy value is equal to or
greater than the max energy compensation value.
Change the amplitude step or maximum
energy compensation limit through the
Alarm Information screen or Setup menu.
2000a
2000dt
Amp Step Conflict The amplitude step value is equal to or greater
than the peak power cutoff value. This alarm is in
all modes but peak power.
Change the amplitude step or peak
power cutoff through the Alarm
Information screen or Setup menu.
2000a
2000dt
Amp Step Conflict The amplitude step at time value is equal to or
greater than the maximum timeout value. This
occurs in all modes except time.
Change the amplitude step at time value
and/or the maximum timeout value
through the Alarm Information screen or
Setup menu.
2000a
2000dt
2000e
Cutoff Conflict The minus reject power limit is equal to or greater
than the peak power cutoff value.
Change the - reject power limit or peak
power cutoff through the Alarm
Information screen or Setup menu.
