Branson 2000X - Page 244

Chapter 7: Maintenance
System Alarm Tables
7-26 011-003-991 EN
+R Freq Limit +R Freq Limit The system Bandwidth
Limit (SBL) function has
determined the frequency
has risen too much and is
now close to the series
resonant point.
Verify integrity of stack.
Review application.
-R PMC Band Limit -R PMC Band Limit The Power Match Curve
function has detected points
below the acceptable curve.
Run additional cycles to
determine if this is a trend or
an anomoly. Examine
process and adjust
accordingly.
+R PMC Band Limit +R PMC Band Limit The Power Match Curve
function has detected points
above the acceptable
curve.
Run additional cycles to
determine if this is a trend or
an anomoly. Examine
process and adjust
accordingly.
2000dt - R Weld Force Limit - Reject Weld Force
Limit
The actual Weld Force did
not reach the minus reject
Weld Force limit.
Adjust - reject weld force
through the Alarm
Information screen or Setup
menu. Discard the part if you
encounter numerous or
successive alarms.
2000a
2000dt
2000e
- R Time Limit - Reject Time Limit The actual time value did
not reach the minus reject
time limit.
Discard the part if you
encounter numerous or
successive alarms with good
parts. Consider changing
your Time settings.
Table 7.7 Suspect/Reject Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Printer Message
Alarm Condition/
Cause
Corrective Action
