Branson 2000X - Suggested Spares

Chapter 7: Maintenance
Parts Lists
7-6 011-003-991 EN
NOTE
i
Cables identified for ‘CJ-20 Converters’ are for those Converters when they are installed in
Branson 2000 Actuators. The Cable connects to the Actuator.
7.2.2 Suggested Spares
* Quantity varies depending on amount of airborne particulate in your environment.
Table 7.3 Suggested Spares
Description EDP# 1-4 Units 6-12 Units14+ Units
Replacement 2000X Control Board 101-063-612 0 1 1
400w power supply module, digital 100-244-064 0 0 1
800w power supply module, digital 100-244-063 0 0 1
1.5kw power supply module, digital 100-244-065 0 0 1
1.125kw power supply module, digital 100-244-046 0 0 1
2.5kw power supply module, digital 100-244-047 0 0 1
3.3kw power supply module, digital 100-244-048 0 0 1
4kW power supply module, digital 159-244-075 1
Front Panel Switch 200-099-252 1 1 2
Line Filter 100-242-489 0 0 1
Line Fuse (s), 20a 200-049-015 2 4 6
DC Fan 100-126-015 2 2 4
Fan Filter Kit 101-063-614 * * *
I/O Board 100-242-288 0 1 2
Line Cord 100-246-947 0 1 2
Front Panel Display 200-220-014 0 1 1
Membrane Panel 100-242-295 0 0 1
DC Power Supply 200-132-294
RF Harness 100-246-949 0 0 1
Keyboard and Bezel 100-246-1055 0 0 1
Front Panel VF Display 200-220-014 0 0 1
