2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual Service Events
011-003-991 EN 7-47
7.6 Service Events
Service events should be performed only by qualified individuals. The potential for injury or
death exists, as well as that for damage to the equipment (which can include loss of product
warranty) or loss of valuable setup information for your application.
When servicing the system, the service person(s) can have a need for certain conventional
hand tools, and you might need to have the following information for testing or returning the
system to service.
7.6.1 Required Tools
Special tools for the ultrasonic Converter, such as spanner wrenches, are provided with your system. You
might also need the following hand tools or service tools:
• six-inch or longer Phillips-head screwdriver with a magnetic tip or screw starter.
• good-quality multi-meter for continuity, AC and DC voltages, and resistance, with insulated test probes.
7.6.2 Voltage Test Points
Remove the cover and pivot the DC Power Supply. See 7.7.6, DC Power Supply.
2000a
2000dt
2000e
Time Extended Weld Time was
Extended for Energy
Compensation
Weld time has been ex-
ended up to 50% for energy
compensation. This alarm
occurs in Time Mode only.
None. This is only a notice
that an adaptive control
feature that you
programmed is in use.
USB Memory Nearly
Full
USB Memory Nearly
Full
The USB memory stick is
over 98% full. At the current
rate of storing, this is
enough room for less than
100 welds. When full the
welder will stop cycling.
Replace USB memory stick.
Table 7.10 Note Alarms (Continued)
Model Display Message Printer Message
Alarm Condition/
Cause
Corrective Action
