Chapter 6: Operation
Setting Primary Parameters
6-22 011-003-991 EN
6.3.3 Using Peak Power Weld Mode
You can use Peak Power Mode to select the maximum percentage of the total available power that will be
used to process your welds. When the power level you set is reached, ultrasonics will be terminated. From
within Peak Power Mode, you can also select several other parameters, ranging from Hold Time (in sec-
onds) to Suspect and Reject Limits. The following two pages contain a map of the menu options in Peak
Power Mode. Procedures for setting primary parameters follow the map. For more information on setting
the optional parameters within Energy Mode, or any other welding mode, see Section 6.4: Setting Other
Weld Parameters, on page 6-30.
