Chapter 4: Installation and Setup
Installation Requirements
4-10 011-003-991 EN
4.4 Installation Requirements
This section covers the location options, dimensions of the major assemblies, environmental
requirements, electrical requirements and factory air requirements, to help you plan and execute
your installation successfully.
4.4.1 Location
The actuator or stand may be installed in a variety of positions. The stand (on a base) is often manually
operated, using its base-mounted start switches, and so is installed at a safe and comfortable workbench
height (approximately 30-36 inches) with the operator sitting or standing in front of the system. Stands (on
hubs) are often used in automated systems and may be manually or automatically loaded and unloaded.
WARNING
The stand may tip over if moved around the axis of its column, if not properly secured. The
work surface on which a stand is installed must be sturdy enough to support it, and secure
enough to not tip over when the stand is adjusted during installation or setup.
The power supply may be located up to 50 feet away for 20kHz, (20' for 30kHz, and 15' for 40kHz models)
from the actuator. The power supply must be accessible for user parameter changes and settings, and must
be placed in a horizontal orientation. The power supply should be positioned so it does not draw in dust, dirt
or material via its rear fans. Refer to the illustrations on the pages that follow for a dimensional drawing of
each component. All dimensions are approximate and may vary between models:
Figure 4.4:
ae Actuator Dimensional Drawing on page 4-10
Figure 4.5: Power Supply Dimensional Drawing on page 4-12
Figure 4.6: Base Mounting Centers on page 4-16
Figure 4.7: Mounting Bolt Pattern for the Hub (for Stand on Hub) on page 4-17
Figure 4.4 ae Actuator Dimensional Drawing
101-240-178 RF, CE - 25’ (J931CS) Note: Not for 30kHz or 40kHz systems
101-240-199 RF, CE - 50’ (J931C)
101-240-179 RF, CE - 8’ (J934C)
continued
101-240-188 RF, CE - 15’ (J934C)
101-240-182 RF, CE - 20’ (J934C)
100-246-630 Ground Detect Cable
100-143-043 Printer, 6’
