Branson 2000X - Chapter 7: Maintenance Parts Lists; Parts Lists

Chapter 7: Maintenance
Parts Lists
7-4 011-003-991 EN
7.2 Parts Lists
This section provides lists of replacement parts, system cables, and suggested spares.Replacement Parts
Table 7.1 Replacement Parts List for 2000X Power Supply
Component EDP Number
DC Power Supply Module* 200-132-294
Line Board* 100-242-489
System Controller Board* 101-063-612
Power Supply Module*
400W / 40 kHz digital 100-244-064
800W / 40 kHz digital 100-244-063
750W / 30 kHz digital 100-244-104
1.5kW / 30 kHz digital 100-244-065
1.25kW / 20 kHz digital 100-244-102
2.5kW / 20 kHz digital 100-244-103
3.3kW / 20 kHz digital 100-244-048
4kW / 20 kHz digital 159-244-075
Switch, On / Off; 15A; DPST 200-099-252
User I/O Board w/ mtg. bracket* 100-246-1054
Washer, Mylar
Kit, 10 each (1/2 in. or 3/8 in.) 100-063-357
Kit, 150 each (1/2 in.) 100-063-471
Kit, 150 each (3/8 in.) 100-063-472
Kit, 10 each (3/8 in., 30 kHz) 100-063-632
Fan 100-126-015
CR2032 Battery for BBRAM 200-262-003
Cover 100-130-378
Cover Screws 100-298-138 (6 ea)
200-298-143 (1 ea)
VF Display 200-220-014
Line Cord 100-246-947
Miscellaneous
Other parts such as wrenches, silicon grease, studs, etc., are found in Chapter 4: Installation and
Setup.
*Each of these items must be replaced as a unit.
