2000X energy Power Supply Chapter 2: The 2000X energy Power Supply
Instruction Manual Compatibility with Branson Products
011-003-991 EN 2-3
2.3 Compatibility with Branson Products
The 2000X Power Supply is designed to be used with:
• 2000ae Actuator (Actuator alone, or Actuator Stand on a Base or on a Hub)
Table 2.1 Power Supply Compatibility with Branson Converters
2.4 Features
2.4.1 The Welding System
The welding system consists of a Power Supply and a converter-booster-horn stack. The system can per-
form ultrasonic welding, inserting, staking, spot welding, swaging, degating, and continuous ultrasonic oper-
ations. It is designed for automated, semi-automated and/or manual production operations.
Listed below are the control features of the Branson 2000-series ultrasonic welding system.
• 1 Millisecond Control and Sampling Rate: This feature provides sampling and control of the weld pro-
cess 1000 times each second.
• 16 Presets: User-configurable setups that can be preset allowing you to simply recall a weld setup to
start production.
• 19” Rack Mount Enclosure: Compatible with industry standard 19” rack enclosure systems. Rack
mount handles are available as an optional kit.
• Adjust While Running: The 2000X allows you to modify the weld parameters while the welder is run-
ning. This can be of benefit in automated systems where you do not want to shut down the entire line to
make a minor modification.
• Afterburst: This feature allows you to turn on the ultrasonics after the weld and hold steps to reliably
2000X energy Model Converter
20 kHz/1250 W
20 kHz/2500 W
20 kHz/3300 W
20 kHz/4000 W
CJ20
CR20
30 kHz/750 W
30 kHz/1500 W
CJ30
CR30
CH30
40 kHz/400 W
40 kHz/800 W
4TH
4TJ
4TP
4TR
