2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual System Alarm Tables
011-003-991 EN 7-43
7.5.7 Overload Alarms
You encounter an overload alarm when your ultrasonic power supply has overloaded. The specific overload
that has occurred is indicated by the message on your display or your printer.
The following table details the overload alarms that you can encounter on the 2000X Power Supply. The
message on the display panel of the Power Supply is shown in the first column, with the more detailed mes-
sage that you can print shown in the second column. The third and fourth columns indicate what condition
led to the alarm and the corrective action you should take.
2000dt + - Trg Limit
Crossed
The reject limits for trigger distance that you have
entered are reversed.
Change the reject trigger distance limits
through the Alarm Information screen or
Setup menu.
2000dt + - Trg Limit
Crossed
The suspect limits for trigger distance that you
have entered are reversed.
Change the suspect trigger distance
limits through the Alarm Information
screen or Setup menu.
2000dt Trg Force Conflict The trigger force is equal to or greater than the
plus suspect weld force limit
Change the trigger force and/or the
+suspect weld force limit through the
Alarm Information screen or Setup menu.
2000dt Trg Force Conflict The trigger force is equal to or greater than the
plus reject weld force limit.
Change the trigger force and/or the
+reject weld force limit through the Alarm
Information screen or Setup menu.
2000dt - R Trg >- R Abs The reject lower limit you have set for trigger is less
than the lower limit you have set for absolute
distance.
Change the reject limits for trigger
distance and/or the limits for the absolute
distance.
2000dt +R Trg >+R Abs The reject upper limit you have set for trigger is
greater than the upper limit you have set for
absolute distance.
Change the reject limits for trigger
distance and/or the limits you have set for
absolute distance.
2000dt - S Trg > - S Abs The suspect lower limit you have set for trigger is
less than the lower limit you have set for absolute
distance.
Change the suspect limits for trigger
distance and/or the limits you have set for
absolute distance.
2000dt +S Trg > +S Abs The suspect upper limit you have set for trigger is
greater than the upper limit you have set for
absolute distance.
Change the suspect limits for trigger
distance and/or the limits you have set for
absolute distance.
2000dt - S Trg > +S Abs The minus suspect trigger limit is equal to or
greater than the plus suspect absolute limit.
Change the - suspect trigger limit and/or
the +suspect absolute limit through the
Alarm Information screen or Setup menu.
2000dt +S Trg > - S Abs The plus suspect trigger limit is equal to or greater
than the plus suspect absolute limit.
Change the +suspect trigger limit and/or
the - suspect absolute limit through the
Alarm Information screen or Setup menu.
Table 7.8 Setup Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Alarm Condition/Cause Corrective Action
