Branson 2000X - Alarm Condition

Chapter 7: Maintenance
System Alarm Tables
7-16 011-003-991 EN
Recalibrate Actuator
Error Code = 200
Recalibrate Actuator A collapse of more than
0.2500” and less than 35
lbs. of force was reached.
Run an Actuator Calibration
procedure from the Alarm Information
screen or from Calibrate in the Main
Menu.
Also check part alignment.
Recalibrate Actuator
Error Code = 300
Recalibrate Actuator A change in horn weight of
6-7 lbs since the last power
down or E-stop.
Run an Actuator Calibration
procedure from the Alarm Information
screen or from Calibrate in the Main
Menu.
Recalibrate Actuator
Error Code = 400
Recalibrate Actuator Carriage travel greater than
-0.25 after trigger.
Run an Actuator Calibration
procedure from the Alarm Information
screen or from Calibrate in the Main
Menu.
Check Step Force and Hold Force for
large decreased values.
Recalibrate Actuator
Error Code = 600
Recalibrate Actuator Actuator type has changed,
d to f or f to d.
Run an Actuator Calibration
procedure from the Alarm Information
screen or from Calibrate in the Main
Menu.
Recalibrate Actuator
Error Code = 700
Recalibrate Actuator In Horn Down, a bad Trigger
has occurred.
Run an Actuator Calibration
procedure from the Alarm Information
screen or from Calibrate in the Main
Menu.
Recalibrate Actuator
Error Code = 800
Recalibrate Actuator Part contact flag has been
lost.
Run an Actuator Calibration
procedure from the Alarm Information
screen or from Calibrate in the Main
Menu.
Recalibrate Actuator
Error Code = 900
Recalibrate Actuator Carriage travels greater
than 0.250 and less than 35
lbs. force was developed
after part contact and before
trigger.
Run an Actuator Calibration
procedure from the Alarm Information
screen or from Calibrate in the Main
Menu.
Check Step Force and Hold Force for
large increasing values.
Recalibrate Actuator
Error Code = 1000
Recalibrate Actuator Upgrade from version 6.00
aed to version 8.0 has been
detected.
Run an Actuator Calibration
procedure from the Alarm Information
screen or from Calibrate in the Main
Menu, using maximum stroke length.
Recalibrate Actuator
Error Code = 1100
Recalibrate Actuator Upgrade from version 8.06
to 8.04 or 8.05 has been
detected.
Run an Actuator Calibration
procedure from the Alarm Information
screen or from Calibrate in the Main
Menu.
Table 7.5 Failure of Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Printer Message
Alarm Condition/
Cause
Corrective Action
