2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual System Alarm Tables
011-003-991 EN 7-17
Recalibrate Actuator
Error Code = 1200
Recalibrate Actuator A Reset Act. Cal has been
done. The restored value is
from an 8.04 or 8.05
calibration.
Run an Actuator Calibration
procedure from the Alarm Information
screen or from Calibrate in the Main
Menu.
2000a
2000dt
2000e
2000t
Start Sw Time Start Switch Stagger
Time Missed
You did not activate both
start switches within the
required time interval.
Activate both start switches at the
same time to rerun the cycle.
2000a
2000dt
2000e
2000t
Start Switch Closed Start Switch Closed
Failure
The start switch(es) are still
active two seconds after the
carriage is home (ULS is
active).
For manual operation: Release the
Start Switches when the beep sounds.
For automated operation: The PLC
(Programmable Logic Controller)
should release the start signal when
the Weld On signal or Start Switch
release signal is active.
Start Switches Lost Start Switches Lost Checked after both start
switches, and before
trigger.There is a 10 ms
debounce time before
considered lost.
Press start switches again.
2000a
2000dt
2000e
2000t
Thermal Overload Thermal Overload Thermal sensors on the
Power Supply indicate that
the temperature is above
the maximum operating
temperature.
Lower the duty cycle by decreasing
the on time or increasing the off time.
Ensure fans are operational and
internal components are free of dust.
Trigger Switch Trigger Switch Trigger Switch Failed.
Checked during ready,
during test ready and during
power up.
The Recal Actuator line and submenu
will only appear on AED or AEF
actuators. Doing a calibration will
reset this alarm.
2000a
2000dt
2000e
2000t
Ultrasonics P/S Ultrasonics Power
Supply Not Present
or Failed
Checked during power up.
Seek was requested but no
run signal detected, or the
amplitude from the Power
output is less than 2%. A
DUPS communication error
occurred.
Contact Branson. Repair/replace the
Power Supply Module.
2000a
2000dt
2000e
2000t
Upper Limit Switch Upper Limit Switch
Failed
Upper Limit Switch was not
engaged at the end of weld
cycle. The switch might
have failed or the electrical
wiring might be loose.
Verify the electrical connections for
the Upper Limit Switch or replace the
switch.
Table 7.5 Failure of Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Printer Message
Alarm Condition/
Cause
Corrective Action
