2000X energy Power Supply Appendix A Remote Terminal
Instruction Manual
011-003-991 EN A-1
Appendix A Remote Terminal
A.1 Setting Up the Remote Terminal - - - - - - - - - - - - - - - - A - 2
A.2 Starting the Remote Terminal- - - - - - - - - - - - - - - - - - A - 2
A.3 Control by the Remote Terminal - - - - - - - - - - - - - - - - A - 2
A.4 Using the Remote Terminal - - - - - - - - - - - - - - - - - - - A - 5
A.4.1 Remote Terminal Keyboard Equivalents - - - - - - - - - - - A - 5
A.5 Viewing Weld Data - - - - - - - - - - - - - - - - - - - - - - - A - 6
A.6 Switching Control Back to the Front Panel - - - - - - - - - - - A - 7
A.7 Turning Off the Remote Terminal - - - - - - - - - - - - - - - - A - 8
The non-intelligent Remote Terminal and keyboard option for the 2000 Power Supply is an alternate user
interface that allows you to view Power Supply menus in their entirety and to navigate through them without
the scrolling that the Power Supply Front Panel requires. This appendix describes the setup and operation
of the Remote Terminal.
The Parameters and Terminal Keyboard equivalents described in this Appendix are those for the Branson-
provided Remote Terminal device. Your terminal’s keyboard operations should be similar if not identical, but
are dependent on your terminal, the keyboard your terminal uses, and any custom-written terminal com-
mands that have been developed for your application.
