Branson 2000X - For a 20 Khz System; For a 30 Khz System

2000X energy Power Supply Chapter 4: Installation and Setup
Instruction Manual Assemble the Acoustic Stack
011-003-991 EN 4-39
4.9.1 For a 20kHz System
4.9.2 For a 30kHz System
Step Action
1
Clean the mating surfaces of the converter, booster, and horn. Remove any
foreign material from the threaded holes.
2
Install the threaded stud into the top of the booster. Torque to 450 in-lbs,
50.84Nm. If the stud is dry, apply 1 or 2 drops of a light lubricating oil before
installing.
3
Install the threaded stud into the top of the horn. Torque to 450 in-lbs, 50.84Nm.
If the stud is dry, apply 1 or 2 drops of a light lubricating oil before installing.
4
Install a single Mylar washer (matching the size of the washer to the stud) to
each interface.
5 Assemble the converter to the booster and the booster to the horn.
6
Torque to 220 in-lbs, 24.85 Nm. (Torque 20kHz Solid Mount Converter to 250 in-
lbs, 28.25 Nm)
Step Action
1
Clean the mating surfaces of the converter, booster, and horn. Remove any
foreign material from the threaded holes.
2
Apply a drop of Loctite® 290 (or equivalent) to the studs for the booster and
horn.
3
Install the threaded stud into the top of the booster; torque to 290 in-lbs,32.76
Nm, and let cure for 30 minutes.
4
Install the threaded stud into the top of the horn; torque to 290 in-lbs, 32.76 Nm,
and let cure for 30 minutes.
5
Install a single Mylar washer (matching the size of the washer to the stud) to
each interface.
6 Screw the converter onto the booster.
7 Torque to 185 in-lbs, 21 Nm.
8
Slide the booster/converter assembly into the adapter sleeve. Screw on the
adapter sleeve ring nut and leave loose.
9 Screw the booster onto the horn.
