Branson 2000X - Environmental Specifications; Electrical Input Power Ratings

2000X energy Power Supply Chapter 4: Installation and Setup
Instruction Manual Installation Requirements
011-003-991 EN 4-13
4.4.2 Environmental Specifications
4.4.3 Electrical Input Power Ratings
Plug the Power Supply into a single-phase, grounded, 3-wire, 50 or 60 Hz power source. Table 4.4 lists the
current and fuse ratings for the various models.
Table 4.4 Input Power Requirements
* requires a special 20 amp 120V receptacle
Table 4.3 Environmental Specifications
Environmental Concern Acceptable Range
Humidity 30% to 95%, non-condensing
Ambient Operating Temperature +5°C to +50°C (41°F to 122°F)
Storage / Shipping Temperature
-25°C to +55°C (-13°F to +131°F);
Up to +70°C (+158°F) for 24 hours
For 20 kHz models
1250 W 200V - 240V 7 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
1250 W 100V - 120V 13 Amp Max. @ 100V / 20 Amp fuse NEMA 5-15P Plug
2500 W 200V - 240V 13 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
3300 W 200V - 240V 19 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
4000 W 220V - 240V 21 Amp Max. @ 220V / 25 Amp fuse NEMA L6-20P Plug
For 30 kHz models
750 W 100 - 120V
750 W 200 - 240V
1500 W 100V - 120V* 20 Amp Max. @ 100V / 20 Amp fuse NEMA 5-20P Plug
1500 W 200V - 240V 10 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
For 40 kHz models
400 W 200V - 240V 3 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
400 W 100V - 120V 5 Amp Max. @ 100V / 20 Amp fuse NEMA 5-15P Plug
800 W 200V - 240V 5 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
800 W 100V - 120V 10 Amp Max. @ 100V / 20 Amp fuse NEMA 5-15P Plug
