2000X energy Power Supply Chapter 5: Technical Specifications
Instruction Manual Standard Modules and Components
011-003-991 EN 5-5
5.3 Standard Modules and Components
The following sections describe the 2000X internal circuits.
5.3.1 Circuit Descriptions
The 2000X Power Supply contains the following modules:
• Line Board
• System Control Board
• Ultrasonic Power Module
• DC Power Module
•User I/O
The following sections contain descriptions for each module.
Line Board
The Line Board performs the dual function of providing RFI filtering for the line voltage input to the power
supply, and controlling the electrical current surge to the ultrasonic Power Supply Module at power up until
the inrush current limiter relay engages. The filtering also blocks ultrasonic signals from entering the AC
main line. Additionally, the Line Board contains a soft start circuit module which limits the effects of current
inrush.
System Control Board
The System Control Board controls the following functions of the Power Supply:
• Responding to start and stop signals
• Responding to alarm and reset signals
• Responding to user input from the front panel
• Activating and monitoring ultrasonics
• Provides information for Front Panel Displays
• Generate alarms
• Activate printing
• Control communications
