Chapter 7: Maintenance
System Alarm Tables
7-12 011-003-991 EN
7.5.2 Cycle Modified Alarms
Table 7.4 Cycle Modified Alarms and Messages, with Probable Cause
and Corrective Action
Model
Display
Message
Printer Message
Alarm Condition/
Cause
Corrective Action
2000f ABS Cutoff Absolute Distance
Cutoff
The absolute distance
cutoff you set was reached.
The main parameter you set
for the weld cycle was not
used to the end of the cycle.
Manually inspect the part. If
the part is acceptable, you
might want to adjust your
main parameter to avoid
this alarm.
2000a
2000f
2000e
2000t
Ground Detect Abort Ground Detect Abort The cycle was aborted
because ground detect
occurred during Weld or
Hold
Manually inspect the part. If
the part is acceptable, you
might want to adjust your
main parameter to avoid
this alarm.
2000a
2000f
2000e
2000t
Ground Detect Abort
(Message also
appears in “No Cycle
Alarms and
Messages.”
Ground Detect Abort The cycle was aborted
because ground detect
occurred during weld or
hold.
Verify part placement and
distance parameters.
2000a
2000f
2000e
Max Timeout Max Timeout The ultrasonics ran for the
maximum allowed time
because the set parameter
could not be achieved.
Manually inspect the part. If
the part is acceptable, you
might want to adjust your
main parameter to avoid
this alarm.
2000a
2000f
No Amplitude Step Time Value for
Amplitude Step not
Reached
The amplitude time step
trigger was not reached.
Manually inspect the part. If
the part is acceptable, turn
amplitude stepping off. If
the part is not acceptable,
you might want to adjust
your main parameter.
No Amplitude Step External signal for
Amplitude Step did
not occur
The amplitude step at
external signal input was
not received.
Make sure Ext Signal is
defined in the User I/O.
2000a
2000f
No Amplitude Step External signal for
Amplitude Step did
not occur
The amplitude step at
external signal input was
not received.
Manually inspect the part. If
the part is acceptable, turn
amplitude stepping off. If
the part is not acceptable,
you might want to adjust
your main parameter.
