2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual System Alarm Tables
011-003-991 EN 7-13
2000a
2000f
No Amplitude Step Power level for
Amplitude Step not
Reached
The amplitude power step
level was not reached.
Manually inspect the part. If
the part is acceptable, turn
amplitude stepping off. If
the part is not acceptable,
you might want to adjust
your main parameter.
2000a
2000f
No Amplitude Step Energy Value for
Amplitude Step not
Reached
The amplitude energy step
trigger was not reached.
Manually inspect the part. If
the part is acceptable, turn
amplitude stepping off. If
the part is not acceptable,
you might want to adjust
your main parameter.
2000f No Amplitude Step Collapse Distance for
Amplitude Step not
Reached
The amplitude collapse
distance step trigger was
not reached.
Manually inspect the part. If
the part is acceptable, turn
amplitude stepping off. If
the part is not acceptable,
you might want to adjust
your main parameter.
Sonics Disabled Ultrasonics Disabled
by user input
Remove Sonics Disable
input.
2000a
2000f
2000e
Peak Power Cutoff Peak Power Cutoff The peak power cutoff was
reached. The main
parameter you set for the
weld cycle was not used.
Manually inspect the part. If
the part is acceptable, you
might want to adjust your
main parameter to avoid
this alarm.
2000a
2000f
2000e
2000t
Trigger Lost in Hold Trigger Lost during
Hold
The cycle was aborted
because trigger force on the
part was lost.
Verify that there is adequate
pressure from your
pneumatic supply.
2000f Trigger > Weld Force Trigger is greater
than the Weld Force
The force at the end of the
weld is less than the trigger
force you set.
Increase your downspeed
and/or system pressure. If
you very frequently receive
this alarm, contact Branson
Trigger Lost in Weld Trigger Lost during
Weld
The cycle was aborted
because trigger force on the
part was lost.
Verify that there is adequate
pressure from your
pneumatic supply. Verify
stroke length < 3.75”
Table 7.4 Cycle Modified Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Printer Message
Alarm Condition/
Cause
Corrective Action
