2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual System Alarm Tables
011-003-991 EN 7-19
7.5.4 No Cycle Alarms and Messages
Table 7.6 No Cycle Alarms and Messages, with Probable Cause
and Corrective Action
Model
Display
Message
Printer Message Alarm Condition/Cause Corrective Action
2000dt Abs Before Trg Absolute Distance
Before Trigger
The absolute distance has been
reached before trigger. This
alarm in other modes means the
absolute cutoff distance has
been reached before trigger.
Reset your absolute
distance parameter through
the Alarm Information
screen or the Setup menu.
2000a
2000dt
Amp Step Before Trg Amp Step Before
Trigger
The amplitude step trigger has
been detected within 2 ms of
start of weld time.
Reset your amplitude step
parameter through the
Alarm Information screen or
the Setup menu.
Trg Delay Timeout External Trigger
Delay Timeout
Ext trigger delay has been
turned on, but the assigned input
did not go inactive within the 30
seconds allowed.
Check external timing.
Activate Ext Trg Delay.
Ground Detect Ground Detect Cutoff The ground detect input is either
improperly configured, in the
wrong condition or failed.
Reconfigure properly,
change condition or replace
faulty input.
Ground Detect Abort
(This message also appears
in the Cycle Modified
Alarms and Messages.)
Ground Detect Abort The cycle was aborted because
ground detect occurred before
trigger.
Verify part placement and
distance parameters.
2000dt Missing Part Abort Missing Part Abort Checked during
downstroke.
The missing part minimum
distance has not been reached
before trigger occurred or the
maximum distance has been
exceeded before trigger
occurred.
Insert a part into the fixture.
Use the horn down feature
to determine the distance to
the part, and reset the
minimum and maximum
settings as necessary
through the Alarm Informa-
tion screen or Setup menu.
2000dt Trig Before Pretrig Trigger Before
Pretrigger
The cycle was aborted because
the trigger force was reached
before the pretrigger distance.
Reset your pretrigger
distance in the setup menu.
Trig Before Pretrig Trg before Pretrg Trigger has occurred before pre-
trigger distance, upper limit
switch is inactive, or pre-trigger
time delay has not timed out.
Check each condition and
correct where necessary.
2000a
2000dt
2000e
2000t
Trigger Timeout Trigger Timeout Trigger force was not achieved
within the 10 second allowed
time.
Verify that the part is in the
fixture; verify that there is
adequate pressure from
your pneumatic supply.
Verify stroke length <3.75”
