2000X energy Power Supply Chapter 4: Installation and Setup
Instruction Manual Installation Steps
011-003-991 EN 4-19
3. Lift the actuator assembly into position on your mount, and secure using the metric bolts provided.
In the event you must use bolts of a different length, ensure that the bolts extend more than
0.25 inch (6 mm) into the threads in the actuator housing, but less than 0.40 inch (10 mm).
4.5.4 Mount the Power Supply
The power supply is designed to be placed on a workbench (rubber feet on bottom) within cable-length limits
of the actuator, or it may be rack-mounted in a standard 19-inch Rack (using an optional rack mount handle
kit). It has two rear-mounted fans which draw cooling air from rear to front, which must be free from
obstruction. Do not place the power supply on the floor or in other locations that will allow dust, dirt or con-
taminants to be drawn into the power supply.
The controls on the front of the power supply must be accessible and readable for setup changes.
All electrical connections are made to the rear of the power supply, which should be positioned in your
workspace with adequate clearance (approximately 4 inches or more on either side, and 6 inches to the
rear) for cable access and ventilation. Do not place anything on top of the power supply case.
See Figure 4.5 on page 4-12
for a dimensional drawing of the 2000 Power Supply.
