Branson 2000X - Chapter 7: Maintenance Parts Replacement

Chapter 7: Maintenance
Parts Replacement
7-52 011-003-991 EN
Figure 7.3 Exploded View of all 2000 Modules
Analog
Ultrasonic Power Supply Module
TopView
J13
J13
Controller
Board
J24 J21
J51
J53
Nose
Assembly
System
Control
Board
Digital
Ultrasonic Power Supply Module
TopView
J13
J13
Controller
Board
J24 J21
J51
Nose
Assembly
System
Control
Board
J60
Line Board
EDP 100-242-489
DC Power Supply Module
EDP 200-132-294
(Fuses EDP 200-029-015)
Remove two screws to pivot DC power supply
Cover
EDP 100-032-378
(7 screws)
100-298-138 (6)
200-258-143 (1)
User I/O Board
EDP 100-246-1054
System Controller Board
EDP 101-063-612
Power Switch
Ultrasonic Power Supply Module
(see Table 7-1)
Fans
EDP 100-126-015
