2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual Parts Replacement
011-003-991 EN 7-61
7.7.12 Cooling Fans
To remove a Cooling Fan, take the following steps:
To reinstall the a Cooling Fan, reverse the removal procedures while observing
the direction of air flow.
Be sure that you reinstall the fan shields on the back of the Power Supply.
Table 7.20 Removing a Cooling Fan
Step Action
1 Turn off the Power Supply.
Unplug the main power.
2
Using a #2 Philips screwdriver, remove 7 screws from the 2000X cover
(3 on each side, 1 on the rear). Remove the cover.
Allow at least two minutes for capacitor discharge.
3
Rotate the DC Power Supply up to allow you access to the Fans. See
7.7.6 DC Power Supply.
4 Cut the tie-wraps from the fan wiring.
5 Disconnect the electrical connector(s).
6 Remove the 4 fan mounting screws and nuts.
7 Remove the fan and shield.
