Branson 2000X - Chapter 4: Installation and Setup Guards and Safety Equipment

Chapter 4: Installation and Setup
Guards and Safety Equipment
4-36 011-003-991 EN
Figure 4.16 Actuator Emergency Stop Button
If you are using an Emergency Stop signal from the Start Switch cable, you must clear the Emergency Stop
condition before the System will operate.
WARNING
The Emergency Stop should be engaged prior to removing the door.
The 2000 Series control system has been desingned to conmform to the safety requirements of NFPA 79,
EN 60204-1 and CFR 1910.212.
Two Hand Control of the 2000 Series control system has been designed to comply with Type 3 of NFPA,
and Type III of EN 60204-1.
The Emergency Stop functions as a category 0 stop of both NFPA 79 and EN 60204-1.
Column
Base
Start SwitchStart Switch
Emergency Stop Knob
