Branson 2000X - Suspect;Reject Alarms and Messages

2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual System Alarm Tables
011-003-991 EN 7-21
7.5.5 Suspect/Reject Alarms and Messages
Table 7.7 Suspect/Reject Alarms and Messages, with Probable Cause
and Corrective Action
Model
Display
Message
Printer Message
Alarm Condition/
Cause
Corrective Action
2000dt + R Col Dist Limit + Reject Collapse
Distance Limit.
The collapse distance used
in the most recent weld was
greater than the upper
reject limit you set.
Discard the part. If you
encounter numerous or
successive alarms with good
parts, you might change your
reject collapse distance
limits.
2000dt + S Col Dist Limit + Suspect Collapse
Distance Limit.
The collapse distance used
in the most recent weld was
greater than the upper
suspect limit you set.
Manually inspect the part for
a good weld. If you
encounter numerous or
successive alarms with good
parts, you might change your
suspect collapse distance
limits.
2000dt + S Trg Dist Limit + Suspect Trigger
Distance Limit
The trigger distance used in
the most recent weld was
greater than the upper
suspect limit you set.
Manually inspect the part for
a good weld. If you
encounter numerous or
successive alarms with good
parts, you might change your
suspect trigger distance
limits.
2000dt +R Abs Dist Limit +Reject Absolute
Distance Limit
The actual distance value
exceeded the plus reject
absolute distance limit.
Discard the part if you
encounter numerous or
successive alarms with good
parts. Consider changing
your Absolute settings.
2000a
2000dt
2000e
+R Energy Limit +Reject Energy Limit The actual energy value
exceeded the plus reject
energy limit.
Discard the part if you
encounter numerous or
successive alarms with good
parts. Consider changing
your Energy settings.
2000dt +R Weld Force Limit +Reject Weld Force
Limit
The actual Weld Force
exceeded the plus Reject
Weld Force limit.
Discard the part if you
encounter numerous or
successive alarms with good
parts. Consider changing
your Weld Force settings.
2000a
2000dt
2000e
+R Pk Power Limit +Reject Peak Power
Limit
The actual peak power
value exceeded the plus
reject peak power limit.
Discard the part if you
encounter numerous or
successive alarms with good
parts. Consider changing
your Peak Power settings.
