Branson 2000X - Page 240

Chapter 7: Maintenance
System Alarm Tables
7-22 011-003-991 EN
2000a
2000dt
2000e
+R Time Limit +Reject Time Limit The actual time value
exceeded the plus reject
time limit.
Discard the part if you
encounter numerous or
successive alarms with good
parts. Consider changing
your Time settings or your
reject time limits.
2000dt +R Trg Dist Limit +Reject Trigger
Distance Limit
The actual trigger distance
value exceeded the plus
reject trigger distance limit.
Adjust + reject trigger
distance limit through the
Alarm Information screen or
Setup menu. Discard the
part if you encounter
numerous or successive
alarms.
2000dt +R Weld Force Limit +Reject Weld Force
Limit
Actual Weld Force did not
reach minus reject Weld
Force limit.
Adjust +reject weld force
through the Alarm
Information screen or Setup
menu. Discard the part if you
encounter numerous or
successive alarms.
2000dt +S Abs Dist Limit +Suspect Absolute
Distance Limit
The actual absolute
distance value did not reach
the plus suspect absolute
distance limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust
+suspect trigger distance
limit through the Alarm
Information screen or Setup
menu.
2000dt +S Col Dist Limit +Suspect Collapse
Distance Limit
The actual collapse
distance value exceeded
the plus suspect collapse
distance limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust the
collapse distance value
through the Alarm
Information screen or Setup
menu.
2000a
2000dt
2000e
+S Energy Limit +Suspect Energy
Limit
The actual energy value
exceeded the plus suspect
energy limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust the
Energy value through the
Alarm Information screen or
Setup menu.
Table 7.7 Suspect/Reject Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Printer Message
Alarm Condition/
Cause
Corrective Action
