2000dt +S Weld Force Limit +Suspect Weld Force
Limit
The actual Weld Force
exceeded the plus suspect
Weld Force limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust the
Weld Force value through
the Alarm Information screen
or Setup menu.
2000a
2000dt
2000e
+S Pk Power Limit +Suspect Peak
Power Limit
The actual peak power
value exceeded the plus
suspect peak power limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust the
Peak Power value through
the Alarm Information screen
or Setup menu.
2000a
2000dt
2000e
+S Time Limit +Suspect Time Limit The actual time value
exceeded the plus suspect
time limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust the
Time value through the
Alarm Information screen or
Setup menu or change
suspect time limits.
2000dt +S Trg Dist Limit +Suspect Trigger
Distance Limit
The actual trigger distance
value exceeded the plus
suspect trigger distance
limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust the
Trigger Distance Limit
through the Alarm
Information screen or Setup
menu.
2000dt +R Abs Dist Limit + Reject Absolute
Distance Limit
The absolute distance used
in the most recent weld was
greater than the upper
reject limit you set.
Discard the part. If you
encounter numerous or
successive alarms with good
parts, you might change your
reject absolute distance limit.
2000dt +R Abs Dist Limit + Reject Absolute
Distance Limit
The absolute distance used
in the most recent weld was
greater than the upper
reject limit you set.
Discard the part. If you
encounter numerous or
successive alarms with good
parts, you might change your
reject absolute distance limit.
2000dt +S Abs Dist Limit + Suspect Absolute
Distance Limit
The absolute distance used
in the most recent weld was
greater than the upper
suspect limit you set.
Manually inspect the part for
a good weld. If you
encounter numerous or
successive alarms with good
parts, you might change your
suspect absolute distance
limits.
Table 7.7 Suspect/Reject Alarms and Messages, with Probable Cause
