Branson 2000X - Page 242

Chapter 7: Maintenance
System Alarm Tables
7-24 011-003-991 EN
2000dt - R Abs Dist Limit - Reject Absolute
Distance Limit
The absolute distance used
in the most recent weld was
less than the lower reject
limit you set.
Discard the part. If you
encounter numerous or
successive alarms with good
parts, you might change your
reject absolute distance limit.
2000dt - S Abs Dist Limit - Suspect Absolute
Distance Limit
The absolute distance used
in the most recent weld was
less than the lower suspect
limit you set.
Manually inspect the part for
a good weld. If you
encounter numerous or
successive alarms with good
parts, you might change your
suspect absolute distance
limits.
2000a
2000dt
2000e
+R Energy Limit + Reject Energy Limit The energy used in the
most recent weld was
greater than the upper
reject limit you set.
Discard the part. If you
encounter numerous or
successive alarms with good
parts, you might change your
reject energy limits.
2000a
2000dt
2000e
+S Energy Limit + Suspect Energy
Limit
The energy used in the
most recent weld was
greater than the upper
suspect limit you set.
Manually inspect the part for
a good weld. If you
encounter numerous or
successive alarms with good
parts, you might change your
suspect energy limits.
2000a
2000dt
2000e
Energy Not Reached Energy Not Reached The weld time has been
extended up to 50% and the
minimum energy has still
not been reached.
Discard the part. If you
encounter numerous or
successive alarms with good
parts, you might change your
minimum energy setting.
2000a
2000dt
2000e
- R Energy Limit - Reject Energy Limit The energy used in the
most recent weld was less
than the lower reject limit
you set.
Discard the part. If you
encounter numerous or
successive alarms with good
parts, you might change your
reject energy limits.
2000a
2000dt
2000e
- S Energy Limit - Suspect Energy
Limit
The energy used in the
most recent weld was less
than the lower suspect limit
you set.
Manually inspect the part for
a good weld. If you
encounter numerous or
successive alarms with good
parts, you might change your
suspect energy limits.
Table 7.7 Suspect/Reject Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Printer Message
Alarm Condition/
Cause
Corrective Action
