Branson 2000X - Page 243

2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual System Alarm Tables
011-003-991 EN 7-25
2000a
2000dt
2000e
+ R Pk Power Limit + Reject Peak Power
Limit
The peak power used in the
most recent weld was
greater than the upper
reject limit you set.
Discard the part. If you
encounter numerous or
successive alarms with good
parts, you might change your
reject peak power limits.
2000a
2000dt
2000e
+S Pk Power Limit + Suspect Peak
Power Limit
The peak power used in the
most recent weld was
greater than the upper
suspect limit you set.
Manually inspect the part for
a good weld. If you
encounter numerous or
successive alarms with good
parts, you might change your
suspect peak power limits.
2000a
2000dt
2000e
- R Pk Power Limit - Reject Peak Power
Limit
The peak power used in the
most recent weld was less
than the lower reject limit
you set.
Discard the part. If you
encounter numerous or
successive alarms with good
parts, you might change your
reject peak power limits.
2000a
2000dt
2000e
- S Pk Power Limit - Suspect Peak
Power Limit
The peak power used in the
most recent weld was less
than the lower suspect limit
you set.
Manually inspect the part for
a good weld. If you
encounter numerous or
successive alarms with good
parts, you might change your
suspect peak power limits.
2000dt - R Abs Dist Limit - Reject Absolute
Distance Limit
The actual distance value
did not reach the minus
reject absolute distance
limit.
Discard the part if you
encounter numerous or
successive alarms with good
parts. Consider changing
your Absolute settings.
2000dt - R Col Dist Limit - Reject Collapse
Distance Limit
The collapse distance used
in the most recent weld was
less than the lower reject
limit you set.
Discard the part. If you
encounter numerous or
successive alarms with good
parts, you might change your
reject collapse distance
limits.
-R Freq Limit -R Freq Limit The system Bandwidth
Limit (SBL) function has
determined the frequency
has dropped too much and
is now close to the series
resonant point.
Verify integrity of stack.
Review application.
Table 7.7 Suspect/Reject Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Printer Message
Alarm Condition/
Cause
Corrective Action
