2000X energy Power Supply Chapter 6: Operation
Instruction Manual Using the Horn Down Feature
011-003-991 EN 6-125
6.10 Using the Horn Down Feature
You can use the Horn Down key to verify that your fixture is properly set up or to determine the absolute
distance that the horn needs to travel to weld your parts. After pressing the Horn Down key you can press
the Start Switches, or you can use manual override to bring the horn down to the position you have set
without ultrasonic energy on by using the mechanical stop. Once the horn is in position, you can release the
Start Switches in order to verify your setup. You can also disconnect air and manually bring the horn down
to read distance and align your fixture.
Using the Horn Down Feature
You can use the Horn Down feature on the Power Supply to verify that your fixture is cor-
rectly placed, so that the horn will contact your part properly.
Take this action… To get this result…
Press the Horn Down key. You will see the
Horn Down screen, indicating that you
should press the Start Switches.
Do NOT set Downspeed adjustment knob initially to a value that is greater than 20. Unex-
pected excessive downspeed can create a dangerous situation.
HORN DOWN Pg1of1
Press Start Switches
Until Beep is Heard
To Next Page
